Zetec TOPAZ64 Portable Phased Array UT Instrument

Advanced Portable PAUT, TOFD, FMC, and TFM Inspection System for Industrial NDT

The Zetec TOPAZ64 is a professional-grade portable phased array ultrasonic testing (PAUT) instrument engineered for advanced non-destructive testing applications across aerospace, oil & gas, power generation, petrochemical, manufacturing, and heavy industry. Designed for both field and workshop use, this rugged inspection platform delivers high-performance phased array acquisition, conventional UT capability, TOFD inspection, and advanced Full Matrix Capture (FMC) / Total Focusing Method (TFM) analysis in a compact and reliable portable system.

Built for inspectors who require speed, precision, and flexibility, the TOPAZ64 supports demanding weld inspection, corrosion monitoring, component integrity verification, and critical flaw detection workflows where data quality and repeatability are essential.

---

Why Choose the Zetec TOPAZ64

The TOPAZ64 is recognized as one of the most capable portable phased array instruments in its class. It combines powerful phased array hardware, advanced imaging performance, and an intuitive touchscreen interface to support complex inspections without sacrificing portability.

Key advantages include:

• 64-channel phased array platform for advanced PAUT inspections
• Supports PAUT, conventional UT, TOFD, FMC, and TFM workflows
• Real-time Total Focusing Method (TFM) performance for improved defect characterization
• Integrated UltraVision Touch software for onboard acquisition and analysis
• Suitable for manual and encoded inspections
• Rugged portable design for plant, field, and shutdown environments
• Fast data processing and large internal storage for professional reporting workflows

This makes the TOPAZ64 an excellent solution for inspection teams requiring a versatile all-in-one instrument for high-value industrial assets.

---

Built for High-Performance Industrial Inspection

The Zetec TOPAZ64 is designed to handle a wide range of ultrasonic inspection tasks where conventional flaw detectors may be limited. Its advanced phased array architecture enables high-resolution imaging and flexible scan configuration for complex geometries, welds, corrosion zones, and critical structural components.

The system is commonly used for:

• Weld inspection in pipelines, pressure vessels, and structural steel
• Corrosion mapping and wall loss evaluation
• Crack detection in critical industrial components
• In-service inspection during plant maintenance shutdowns
• Aerospace structural integrity inspection
• Power generation asset inspection
• Petrochemical and refinery inspection programs
• Manufacturing quality assurance and advanced flaw characterization

With support for advanced focal law management and real-time imaging, the TOPAZ64 helps improve defect detectability while reducing inspection time.

---

Advanced PAUT, TOFD, FMC, and TFM Capability

One of the strongest advantages of the Zetec TOPAZ64 is its ability to support multiple advanced inspection methods in a single portable platform.

Phased Array Ultrasonic Testing (PAUT)

The system provides high-quality phased array data acquisition for detailed imaging and flaw analysis, making it suitable for welds, corrosion, and complex part inspections.

Time of Flight Diffraction (TOFD)

TOPAZ64 supports TOFD workflows for accurate crack sizing and defect characterization in weld inspection applications.

Full Matrix Capture (FMC) and Total Focusing Method (TFM)

For users requiring more advanced imaging, the TOPAZ64 supports FMC and TFM workflows, enabling highly detailed visualization of reflectors and improved interpretation of complex indications. TFM can be especially valuable in applications where defect discrimination and imaging clarity are critical.

Conventional Ultrasonic Testing (UT)

In addition to phased array functionality, the system also supports conventional UT channels, making it practical for mixed inspection requirements.

---

Integrated UltraVision Touch Software

The TOPAZ64 includes integrated UltraVision Touch software, providing onboard acquisition, real-time analysis, and inspection workflow management directly from the instrument.

Benefits of the onboard software environment include:

• Streamlined inspection setup
• Real-time data acquisition and display
• Efficient focal law and scan configuration
• Touchscreen-based workflow control
• Faster interpretation during field inspection
• Improved portability without requiring a separate PC for many tasks

This integrated workflow is especially useful for field crews who need fast deployment and reliable inspection performance in industrial environments.

---

Rugged Portable Design for Field and Plant Use

The Zetec TOPAZ64 is designed for real-world NDT environments where portability, durability, and usability matter. The instrument’s rugged housing and integrated touchscreen interface allow operators to work effectively in refineries, fabrication shops, offshore maintenance projects, and power generation facilities.

Its portable design makes it suitable for:

• Shutdown and turnaround inspection work
• Elevated access or confined inspection areas
• On-site weld quality verification
• Remote field inspection assignments
• Service teams requiring transportable advanced UT capability

This balance of performance and portability is one of the key reasons the TOPAZ64 is widely selected for professional inspection teams.

---

Typical Applications

The Zetec TOPAZ64 is widely used in industries where advanced flaw detection and high-confidence inspection data are required.

Oil & Gas / Petrochemical

• Pipeline weld inspection
• Pressure vessel examination
• Corrosion monitoring
• Refinery shutdown inspections
• Process piping integrity programs

Power Generation

• Boiler and pressure component inspection
• Turbine and plant maintenance inspection
• Weld integrity assessment
• Critical asset life extension programs

Aerospace

• Structural flaw detection
• Bond and material inspection
• Component integrity verification
• Maintenance and overhaul programs

Manufacturing / Heavy Industry

• Fabrication weld quality control
• Thick-section inspection
• Structural steel inspection
• Advanced flaw characterization

---

Key Features

• 64-channel phased array ultrasonic inspection platform
• Supports PAUT, TOFD, conventional UT, FMC, and TFM
• Integrated UltraVision Touch acquisition and analysis software
• Portable all-in-one touchscreen design
• High-speed real-time imaging for advanced NDT workflows
• Large internal SSD storage for inspection data
• HDMI output and multiple connectivity options
• Suitable for encoded and manual inspection applications
• Designed for advanced weld inspection, corrosion, and flaw characterization

---

Technical Specifications

Below is a professional reference specification set for the Zetec TOPAZ64. Configuration may vary depending on software package, licensing, probe setup, and system revision.

Specifications may vary depending on software license, instrument revision, and supplied configuration.

---

Condition & Supply Information

Each available unit is intended for professional industrial inspection use and may be supplied depending on current stock availability.

Typical supply condition may include:

• Tested and verified for operation
• Good working condition
• Available with standard accessories
• Calibration certificate or documentation depending on stock package
• Export-safe packing for international shipment

For exact condition details (new, used, pre-owned, or refurbished), please contact us before ordering.

---

Why This Instrument Is Valuable for Inspection Teams

For companies performing advanced weld inspection, corrosion assessment, shutdown maintenance, or high-specification integrity programs, the TOPAZ64 offers a strong balance of performance, portability, and advanced imaging capability.

It is especially valuable when inspection teams need:

• One instrument for multiple UT methods
• Reliable field deployment
• Advanced phased array imaging
• TFM support for improved defect characterization
• Reduced dependence on multiple separate devices
• Better reporting and workflow efficiency

This makes the TOPAZ64 a practical investment for contractors, service companies, inspection departments, and asset integrity teams.

---

Worldwide Supply & Export Support

We supply professional NDT equipment for international buyers and industrial customers worldwide.

Our support may include:

• Competitive export pricing
• Worldwide shipping assistance
• Secure packaging for international transit
• Export documentation support
• Response for technical and commercial inquiries
• Assistance with product availability confirmation

For pricing, stock condition, shipping options, and package details, please contact us to request a quotation.
