Description

FLIR E60 Infrared Camera

The FLIR E60 IR thermal imager offers one of the most effective ways to keep your facility operating at peak performance, avoid expensive equipment failures, and prevent loss of production capacity.

Features

Now with MSX Thermal Image Enhancement – See numbers, labels and other key visual details not normally apparent in a regular thermal image with an all-in-one thermal picture that instantly orients you to right where heat issues are
Its high infrared resolution images of 76, 800 pixels (320 X 240) offers clear and precise displays of wherever the problem may lie
Thermal sensitivity of <0.05°C helps to find the problems faster and easier, a key feature for equipment monitoring
An optimized temperature range of -4 to 1202°F (-20 to 650°C)
Improved digital camera with a 3.1 megapixel resolution to provide the clearest visible light picture
Large 3.5″ landscape touch serene
Wi-Fi Connectivity to send images and data to an iPhone®, iPad®, iPod touch®, or Android™ using FLIR Told Mobile app
Scalable Picture-in-Picture and thermal fustian to overlay visible and thermal images
MeterLink allows to wireless transmit vital diagnostic data from clamp and moisture meters directly to the camera
Annotation allows you to add voice comments via bluetooth headset
InstantReport generates a professional PDF document directly from the camera
Applications
Electrical: Find hidden problems quickly, make timely repairs, prevent unscheduled shutdowns, and improve plant safety.
Mechanical: Discover overheated bearings, linkages, and other components before they can interrupt your operations or create safety hazards.
Utility: Scan large areas and hundreds of connections quickly and efficiently to prevent unexpected service outages and lost revenues.

Large Landscape Touchscreen: Brighter than other brands, the FLIR E-Series touchscreen provides an intuitive interface that takes full advantage of the entire 3.5″ display with no image cropping.

Multiple Measurements: Add up to three box areas and three moveable spots using the touchscreen to gather more detailed temperature information.

Scalable P-i-P and Thermal Fusion: Overlay thermal and visible images for easy location identification and clearer documentation with the 3.1MP visible light camera.

Specifications FLIR E60

Model Number FLIR E60
Imaging
Resolution 320 × 240 pixels
Total Pixels 76,800
Thermal Sensitivity < 0.05° C
Accuracy ±2°C or ±2% of reading
Temperature Range -4°F to 1,202°F (-20°C to 650°C)
Video Camera w/Lamp 3.1 MP
Lens Options Standard: 25°; Optional: 15° Tele, 45° Wide
Zoom 4x Continuous Digital
Focus Manual
Uncooled Microbolometer x
Color LCD Touch Screen 3.5″ (320 x 240 )
Picture-in-Picture Scalable
Fusion x
Laser Spot x
Video Out Composite
Frame Rate 60 Hz
Analysis
Moveable Spots‡ 3
Box Areas 3
Delta T‡ x
Annotation
Voice x
Text x
File Storage
Radiometric JPG to SD Card x
MPEG4 Video Recording x
Other
Wi-Fi to Apple and Andriod Mobile Devices x
MeterLink x
InstantReport x
FLIR Tools x
Battery Type / Op Time Li Ion, 4 hours operating time
Dual-bay Charger and Spare Battery Included
Weight 0.825 kg (1.82 lbs)
Optional Accessories 15° and 45° lenses, sunshield, tripod adapter, cigarette lighter adapter kit, Bluetooth headset, and more
