Olympus Vanta L Series XRF Analyzer

Original price was: $7,900.Current price is: $6,490.

Category: Tag:


Olympus Vanta L Series XRF Analyzer is our most advanced handheld X-ray fluorescence (XRF) device for customers who demand laboratory-quality results in the field. It provides rapid, accurate elemental analysis and alloy identification for high-throughput XRF testing.

Olympus Vanta L Series handheld XRF analyzers are built to be tough. Their rugged, durable design makes them resistant to damage in challenging industrial environments for greater uptime and a lower cost of ownership.

With an intuitive user interface and customizable software, the Vanta XRF series is easy to use with minimal training for high throughput and a fast return on investment. Featuring innovative and proprietary Axon Technology™, Vanta analyzers give you accurate results and help boost productivity no matter the environment or working conditions.

Exceptionally durable under extreme conditions.
Superior analytics.
Optional wireless LAN and Bluetooth® for real-time data sharing. Cloud technology enabled.
Intuitive user interface.

Olympus Vanta L Series XRF Analyzer

Specification :

Dimensions (W x H x D) 8.3 x 28.9 x 24.2 cm (3.25 x 11.4 x 9.5 in.)
Weight 1.70 kg (3.75 lbs) with battery, 1.48 kg (3.25 lbs) without battery
Excitation Source 4-Watt X-ray tube with application optimized anode material (rhodium (Rh), silver (Ag), or tungsten (W)) M Series (Rh & W) and C Series (Ag): 8-50 kV C Series (Rh & W): 8-40 kV
Primary Beam Filtration 8-position auto selected filter per beam per mode
Detector M Series: Large area Silicon Drift Detector C Series: Silicon Drift Detector
Power Removable 14.4 V Li-Ion battery or 18 V power transformer 100-240 VAC, 50-60 Hz, 70 W max
Display 800 x 480 (WVGA) LCD with capacitive touch-screen supporting gesture control
Operating Environment Temperature: -10 °C to 50 °C (continuous duty cycle with optional fan) Humidity: 10% to 90% relative humidity non-condensing
Drop Test Military Standard 810-G 4-foot (1.3 M) drop test
IP Rating IP65*: dust tight and protected against water jets from all directions
Pressure Correction Built-in barometer for automatic altitude and air density correction
GPS Embedded GPS/GLONASS receiver
Operating System Linux
Data Storage 4 GB embedded storage, micro SD slot for expandable storage
USB (2) USB 2.0 type A host ports for accessories such as Wireless LAN Bluetooth®, and USB flash drives. (1) USB 2.0 type mini-B port for connection to computer
Wireless LAN Supports 802.11 b/g/n (2.4 GHz) via optional USB adapter
Bluetooth Supports Bluetooth® and Bluetooth Low-Energy via optional USB adapter
Aiming Camera Full VGA CMOS camera
Panorama Camera 5-megapixel CMOS camera with autofocus lens


Olympus Vanta L Series Analyzer Feautures :

  • 4-Watt X-ray tube: Rh, Ag or W
  • 8 position auto-selected filter per beam per mode
  • GeoChem module included
  • SmartSort automatically lengthens/shortens test time based on material
  • Grade matching delivers real time messages that translate jargon into trade language
  • Compare close grades side by side
  • Wireless LAN, Bluetooth, embedded GPS
  • 800 x 480 (WVGA) LCD display with customizable user interface .

Olympus Vanta L Series Analyzer Applications :

  • RoHS local/international compliance
  • Scan for precious metals – alloy chemistry & karat classification for gold, silver, platinum, rhodium
  • Jewelry analysis
  • Car catalyst recycling.
  • Soil & sediment analysis
  • Manufacturing quality control
  • Mining grade control & geochemical exploration
  • Recycling & scrap sorting
The Following Items Are Included:

Olympus Vanta L Series XRF AnalyzerBattery PackPower CordUser Manual On Cd-ROMCarrying Case (G)
