Zetec TOPAZ16 Portable Phased Array UT Instrument

Compact and Reliable Phased Array UT Solution for Everyday Industrial NDT

The Zetec TOPAZ16 is a compact, field-ready phased array ultrasonic testing (PAUT) instrument built for professional non-destructive testing applications where portability, efficiency, and dependable performance are essential. Designed for common industrial inspection tasks such as weld inspection, corrosion assessment, encoded scanning, and manual flaw detection, the TOPAZ16 offers a strong balance between advanced phased array capability and practical day-to-day usability.

Available in 16/64 and 16/128 configurations, the TOPAZ16 is a fully integrated phased array platform that helps inspection teams perform setup, acquisition, analysis, and reporting from a single portable unit. With embedded UltraVision Touch software and a rugged design made for demanding environments, it is an excellent choice for NDT service providers, plant inspection teams, and industrial asset integrity programs.

---

Why Choose the Zetec TOPAZ16

The TOPAZ16 is designed for inspection professionals who need a practical phased array solution without the size and complexity of larger multi-channel systems. It is especially well suited for common field inspection jobs where reliability and portability matter more than oversized configurations.

Key advantages include:

• Compact and lightweight portable phased array UT instrument
• Available in 16/64 and 16/128 phased array configurations
• Supports phased array UT and conventional UT inspection workflows
• Embedded UltraVision Touch software for onboard setup and analysis
• Rugged housing with no air intake for improved field durability
• Ideal for weld inspection, corrosion mapping, and general industrial NDT
• Upgrade path from 16/64 to 16/128 via software depending on configuration path noted by sellers and brochures

This makes the TOPAZ16 a strong option for companies that need a cost-effective and capable phased array instrument for frequent field deployment.

---

Built for Common High-Value Inspection Applications

The Zetec TOPAZ16 is widely recognized as a highly practical phased array system for routine and intermediate-level industrial inspections. It is designed to handle many of the most common ultrasonic testing tasks while maintaining a compact footprint that is easier to transport and deploy in the field.

Typical applications include:

• Weld inspection for fabrication and maintenance
• Corrosion mapping and wall loss evaluation
• Manual and encoded inspections
• Inspection of pipes, vessels, and structural components
• Maintenance shutdown inspection programs
• General flaw detection in industrial assets
• Quality control in manufacturing and heavy industry

Zetec and reseller materials consistently position TOPAZ16 for weld inspection, corrosion mapping, encoded/manual inspection, and complex component inspection.

---

16/64 and 16/128 Configuration Flexibility

One of the most useful advantages of the TOPAZ16 is its availability in two practical configurations:

TOPAZ16 16/64

• Supports up to 16 active channels with up to 64-element probes
• Well suited for standard phased array applications
• Good option for routine weld inspection and common field jobs

TOPAZ16 16/128

• Supports up to 16 active channels with up to 128-element probes
• Better suited for broader probe compatibility and more flexible inspection setups
• Commonly preferred when more advanced multi-group or expanded probe capability is required

Multiple sources list the two main versions as 16/64 and 16/128.

This configuration flexibility makes the TOPAZ16 attractive for inspection teams that want to start with a practical system and scale capability as project demands increase.

---

Embedded UltraVision Touch Software

The TOPAZ16 includes embedded UltraVision Touch software, allowing users to perform inspection setup, acquisition, analysis, and reporting directly from the instrument. This integrated software workflow helps reduce dependence on external systems for many day-to-day inspections.

Benefits include:

• Faster inspection setup
• Streamlined focal law configuration
• Efficient onboard data review
• Simplified field workflow
• Improved reporting efficiency
• Better portability for mobile inspection crews

Zetec’s brochure explicitly highlights UltraVision Touch onboard as a key selling point.

---

Rugged, Compact, and Field-Ready

The TOPAZ16 is designed for real-world industrial environments where portability and durability directly affect productivity. Its compact footprint and robust metal housing make it easier to transport between inspection sites, while the no-air-intake design helps improve reliability in dusty or challenging field conditions.

This makes the TOPAZ16 well suited for:

• Refinery and petrochemical shutdown work
• Fabrication shop inspections
• Field service contracts
• Power plant maintenance programs
• Elevated or confined work locations
• Remote industrial site deployment

Multiple references note the no air intake design, compact aluminum-style housing, and 4.5 kg class weight.

---

Key Features

• Portable phased array ultrasonic testing instrument
• 16/64 or 16/128 phased array configurations
• 1 conventional UT channel
• 10.4-inch high-resolution multi-touch display
• Embedded UltraVision Touch software
• 256 GB SSD storage
• Ethernet, USB, and HDMI connectivity
• IP66 design reference from technical sheets
• No air intake for improved durability in field environments
• Suitable for weld inspection, corrosion mapping, and general industrial NDT

Technical sheets list 10.4-inch display, 256 GB SSD, Ethernet + USB + HDMI, and IP66 designed.

---

Technical Specifications

Below is a professional reference specification set for the Zetec TOPAZ16. Final supplied configuration may vary depending on version, connector type, software package, and included accessories.

These values align with the published technical sheets and brochures for TOPAZ16.

---

Condition & Supply Information

Available units may be supplied based on current stock and configuration availability.

Typical supply condition may include:

• Tested and verified for operation
• Good working condition
• Main instrument with standard accessories
• Charger and battery package depending on stock
• Carrying or transport case if available
• Documentation or calibration information if available
• Secure export packaging for international shipment

For exact condition details, please contact us to confirm:

• stock availability
• included accessories
• software configuration
• probe / cable compatibility
• shipping destination
• final quotation

---

Worldwide Supply & Export Support

We supply professional NDT equipment for industrial buyers worldwide.

Our support may include:

• Competitive export pricing
• International shipping assistance
• Secure protective packaging
• Export documentation support
• Commercial and technical response for overseas buyers
• Availability confirmation before shipment

Please contact us to request pricing, current availability, and delivery options.
