Trimble RTS 773 Robotic Total Station with best price

Description

Trimble RTS 773 Robotic Total Station with best priceintegrates cutting-edge technologies to deliver a fast, precise, and reliable layout, giving you the freedom to take on even the most challenging projects and guaranteeing that the design concept is executed correctly the first time.

Trimble VISION uses an integrated digital camera that can be controlled remotely with the Trimble Tablet to replace the monitor light on the RTS unit. By using this tablet, users can accomplish tasks like design, data collection, or domain account generation while viewing and recording the real job site condition from the perspective of the RTS773.

Construction-specific performance and one-person operation are offered by the Trimble RTS 773. When conducting layout, gathering data, or writing field reports, view and record the actual job site circumstances from the entire station. Set up quickly anywhere, carry out activities like sizing and layout on your own, and utilize the user-friendly interface. The Trimble RTS 773 gives you the freedom to select construction layout and take field jobs to the next level by combining the DR HP Precision EDM with Trimble VISION.

Trimble VISION, an integrated camera at the robotic total station that provides a “through the telescope perspective” remotely via the Trimble Tablet and Trimble Field Link, is a component of the Trimble RTS 773. Specialty and general contractors who demand precision, quality, and the best possible field performance employ this total station. Surveyors can also boost output.

Trimble RTS 773 KEY FEATURES:

• Trimble VISION having an integrated digital camera
• View and document real job site requirements from the standpoint of the total station when performing design, collecting data or generating field reports
• One individual layout
• Robotic communication link — 2.4 GHz radio
• Robotic radio communication range — 500-700 m (1,640 — 2,297 feet )
• Measuring range (single prism) — 2,500 m (8,202 ft)
• Distance measurement accuracy (prism style ) — +/-2 mm + 2 ppm (0.01 ft + 2 ppm)
• Reflectorless DR measuring — 120 m
• Angle precision — flat: 3″ (1.0 mgon), vertical 2″ (0.6 mgon)
• Visible verification with data overlay and photo verification
• MagDrive technology for maximum speed and efficiency
• MultiTrack technology offers the choice between passive and active monitoring

Trimble RTS 773 Robotic Total Station Package Included  :

• Trimble RTS 773 Robotic Total Station
• Trimble MultiTrack Prism (MT1000) with prism pole and bipod, inc 7.4V Li-Ion battery
• Trimble Kenai Tablet with (Global Radio) Kit
• Two batteries with charger
• Multiple Antennas
• Trimble Field Tablet for MEP
•  Tripod – Dual Clamp Tri-Max with Trimble Logos
•  Trimble Bipod for Inverted Layout Rod
•  Hard Case for the Total Station and prism
• Various other cables, power supplies, and accessories.
