Leica TS13 Robotic Total Station Best Price

Sale!

Leica TS13 Robotic Total Station Best Price

Original price was: $7,800.Current price is: $5,460.

Category: SURVEYING EQUIPMENT Tag: Leica

Description
Reviews (0)

Description

Leica TS13 Robotic Total Station Best Price is a robotic complete station in the midrange. Leica Captivate field software powers this scalable robotic total station, which may be linked to a Leica CS20 field controller. It can be updated whenever you’d like to have access to new features.

To meet the demands of customers who wish to measure and arrange additional points, the Leica TS13 total station offers a quick, dependable, and effective solution. It offers precise target measurement with Automatic Target Recognition (ATR) technology, target lock as an option, and SpeedSearch to swiftly locate and lock on to prisms. The TS13 provides a straightforward and efficient method of coding and line work when used in conjunction with Leica Captivate field software.

Using the cutting-edge Leica Captivate field software, the Leica TS13 transforms complicated data into the most practical and realistic 3D models. Whether you use GNSS, total stations, or both, it can cover a wide range of industries and applications with just a single swipe. Ensuring a seamless data transfer keeps the project moving forward. Leica Infinity office software and Captivate work together to merge past survey results and edit projects more quickly and effectively.

Technical Specifications of Leica TS13 Robotic Total Station

Product Name	Leica Total Station TS13 Robotic TS
Angular Measurement
Accuracy 1 Hz and V	Absolute, continuous, diametrical	1″ (0.3 mgon), 2″ (0.6 mgon), 3″ (1 mgon), 5″ (1.5 mgon)
Distance Measurement
Range 2	Prism (GPR1, GPH1P) 3 Non-Prism / Any surface 4	1.5 m to 3500 m R500: 1.5 m to >500 m, R1000: 1.5 m to >1000 m
Accuracy / Measurement time	Single (prism) 2,5 Single (any surface) 2,4,5,6	1 mm + 1.5 ppm / Typically 2.4 s 2 mm + 2 ppm / Typically 3 s
Laser dot size	At 50 m	8 mm x 20 mm
Measurement technology	System analyser	Coaxial, visible red laser
Automatic Aiming – ATR
Target aiming range2	Circular prism (GPR1, GPH1P) 360° prism (GRZ4, GRZ122)	1000 m 800 m
Accuracy 1,2 / Measurement time	ATR angle accuracy Hz, V	1″ (0.3 mgon), 2″ (0.6 mgon), 3″ (1 mgon), 5″ (1.5 mgon) / Typically 3-4 s
Guide Light (EGL)
Working range / Accuracy		5 – 150 m / Typically 5 cm @ 100 m
General
Processor	TI OMAP4430 1GHz Dual-core ARM® Cortex™ A9 MPCore™	Operating system – Windows® EC7
Power management	Exchangeable Lithium-Ion battery	Operating time 8 – 10 h
Field software	Leica Captivate incl. apps	Running on field controller (Leica CS20)
Data storage	Internal memory 2 GB SD card 1 GB or 8 GB	On field controller (Leica CS20)
Interfaces	RS232, USB, Bluetooth®, WLAN
Weight	Total station including battery	5.0 kg
Environmental specifications	Working temperature range Dust / Water (IEC 60529) / Humidity	–20°C to +50°C IP55 / 95%, non-condensing
Keyboard	Face I standard	4 button keyboard with status LEDs
Keyboard Display Unit (Optional)
Keyboard with display	Face I and face II optional	5” (inch), WVGA, colour, touch 25 keys, illumination
Power management	Exchangeable Lithium-Ion battery	Operating time 6 – 8 h
Field software	Leica Captivate including apps	Running on TS13 instrument
Data storage	Internal memory 2 GB SD card 1 GB or 8 GB	On TS13 instrument
Weight	Total station including battery	5.3 kg
Target Lock (Optional)
Target locking range2	Circular prism (GPR1, GPH1P) 360° prism (GRZ4, GRZ122)	800 m 600 m
Robotic Surveying Including Prism Fast Search (Optional)
SpeedSearch range / Search time	360° prism (GRZ4, GRZ122)	300 m / Typically 7 s
Robotic range with long-range Bluetooth® 8	To CS20 internal long-range Bluetooth® To CTR20 expansion pack	500 m 1000 m
